Engine Make - PERKINS
Engine Model - 4016-61TRG3
No. of Cylinders - 16 60º Vee form
Cycle - 4 Stroke
Aspiration - Quad turbocharged. air to water charge cooled
Cooling Method - Water cooled
Governing Type - Electronic
Governing Class - G2 – ISO 8528 Part 1
Compression Ratio - 13:01
Displacement - 61.123 litres
Bore/Stroke - 160 x 190 mm
Dynamic Charging Alternator - 55AMP, 24V

Alternator Make - Leroy Somer
Alternator Model - LSA52.3 L9
Number of Poles - 4
Number of Winding Leads - 12
Type of Bearing - Single Bearing
Insulation Class – Temp Rise - Cont. H – 125/40 ̊C​
Ingress Protection Rating - IP 23
Excitation System - AREP + PMI
AVR Model - D510C
